The model contains an alternativ volume knob and a bigger VFO Knob.

Additional needed Material:

2x M2.5 x 4mm socket screw (Madenschraube)

Knobs

Material: PLA or PETG
Layerhigh: 0,2 mm
Infill: 20%

Softgrip Ring

In order to put the flat part on the print bed, turn the model 180\u00b0 around before slicing.
(otherwise it will put the roundet top of the ring onto the print bed.

Material: TPU
Layerhigh: 0,2 mm
Infill: 0%

Assembly:

First mount the hard inner knob-core to the radio and fix them with a M2.5x4 socket screw.
The holes are wide enough, a thread is not needed, the screw will do it alone, do not overtighten the screw. Next step is to slip the soft knurled TPU ring over the hard knob core.
