Welding Fence Block 16mm 2in center

These are fencing blocks and locating pins for use on a 2 inch on Center metal Fabrication table with 16 mm holes. Yes they're made of plastic and they will melt if you try and weld too close to them. But they're certainly a lot cheaper than buying the metal ones, and very cheap to replace if they become damaged. Make sure to print with extra wall thickness. Think of this as the super cheap version of Fireball tools.

No cleanup needed they're a little stiff the first time you put them in the table after that they slide in easily and are very rigid. These are plastic and will melt if you weld too close to them it's recommended you use them to locate your metal parts then clamp the metal Parts down and move the fencing blocks as needed.

Print Settings

Rafts:

No

Supports:

No

Resolution:

.3

Infill:

15

Filament: any PLA any
