ESP32 CAM case / enclosure / for thicker ESP32 board

Remix of milans' excellent case to accommodate ESP32cam boards with longer pins.
2
15
0
135
updated August 13, 2024

Description

PDF

When testing the original model I found that it worked great and snapped together perfectly with one hitch.  The leads on the ESP32cam boards I have were too long, preventing the cover from fully seating.  I could have replaced the header or clipped off the leads but where's the fun in that?

I remixed the case bottom to give more room.  I included photos to show how the board sits too high in the original model but seats properly in the remixed model.  There  are versions for both variants of the original case back.

Many thanks to milans!

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

The case back has been stretched so that it is thick enough to fit ESP32cam boards with longer pins.
