Dial indicator support for Tevo Tarantula

A strong, stable (very important) and very convenient dial indicator support that is set at the back side of the Tevo Tarantula X-carriage.

I use it for manually leveling the bed, and to set the nozzle height at the right distance to get a nice first layer.

This design is useful for the dial indicator that can be bought in Aliexpress http://bit.ly/2zvLmud.

The main printed part needs to replace the original back side of the dial indicator using the very same tiny and stock screws.

To hold the dial indicator to the X-carriage, I use two 6mm screws that are tightened to two internal bolts that are introduced into the piece.

To avoid scratching the aluminum or acrylic carriage, I designed and use a protective piece that is to be placed between the end of the screws and the aaluminum/ acrylic.

Print Settings

Printer:

Tevo Tarantula

Rafts:

No

Supports:

No

Resolution:

0,2mm

Infill:

40%
