Mini Vertical Arcade Machine

Wanted a vertical mini arcade so I modded "Mini Arcade Machine" by iClint. I did change it to use all M3 bolt's except…
7
22
0
250
updated December 26, 2023

Description

PDF

Wanted a vertical mini arcade so I modded "Mini Arcade Machine" by iClint. I did change it to use all M3 bolt's except the M2.5's for the SD extender. Also cleaned up some spacing so thing fit better. Check the "Needed parts" for a list of things for this build. The only thing I left off was some speaker wire and needed SD card.

Made 2 Bezel's. One for BigTreeTech's TFT7" and one for the common one's that are out there. The BTT one is nice because it has mounts for Pi right on the back of the screen.

Added volume control and on/off switch. Put a female USB-C on the back so you could power it off a power bank or a plug in power supply. Put a USB port in front for keyboard or controller.

One more thing. Added a remote SD card slot so you can change cards easily.

Enjoy!

Print Settings

Printer:

Folgertech FT-6

Rafts:

No

Supports:

No

Resolution:

.26

Infill:

10%

Filament:

Hatchbox and ZYLtech PLA

N/A


Notes:

Used 4.0 step over so the chamfers come out better. I did use supports on the control deck.

Category: Video Games

Tags



Model origin

The author remixed this model. Imported from Thingiverse.

Mini Arcade Machine
by iClint (thingiverse.com)


Differences of the remix compared to the original

Original has a horizontal screen. This one has a vertical screen.
