Voron Trident 350mm chassis

This is still an untested WIP, but I am uploading in case people like the idea enough to modify to fit other printers.
I intend for the handles to be useable.  A ½" square profile steel pipe is to be tapped and inserted into the top handles, using heat set inserts to screw everything together. (ideally you use a countersink bit to also make the screw flush with the beam) I'll be adding a more in depth BOM and instructions as the design progresses.


I've done my best to ensure that this can be used with Voron spec heat set inserts and the same screws used for the panel clips on stock Voron tridents.

The Side skirts have a insert that is to be printed as hexagonal infill pattern with no perimeter walls or top/bottom layers. printed at 22% infill . This was inspired by the Flat Mesh Bed Skirts for the Voron 2.4 and trident by @Thejiral

be prepared to use about 3.5-4kg of material at least LOL


I want to credit a few others for portions of the model that are remixed to ensure fitment of other components.  I will be updating this as I get the time to. this couldn't have come as far as it did without the works of other's credited!

monolith panels: for the clip mechanism.
https://github.com/CloakedWayne/Monolith_Panels

6mm slot cover
https://mods.vorondesign.com/detail/ZKJgu7OwMNB1xAKRrYSYeg

BTT PITFT50 v2 mount
https://mods.vorondesign.com/detail/Go1zR41hCwy0C1qRubOIcQ

BTT TFT 35-SPI v2.1 Pivoting Display Mount

https://www.printables.com/model/567043-btt-tft35-spi-v21-pivoting-display-mount
