MTG Commander Deck Box - Parametric Vase Mode

A deck box for holding a sleeved commander deck, designed to be printed in spiral vase mode. Parametric F360 model.
1h 12m
1× print file
0.35 mm
0.60 mm
47.00 g
19
92
0
701
updated December 8, 2023

Description

PDF

A Parametric, Vase-Mode Deck Box!

This parametric deck box has been designed to hold a full 100 card MTG commander deck.

Some key parameters for you to play with include:

  • Card Width
  • Card Length
  • Deck Thickness
  • Box Wall Thickness
  • Card Clearance/Tolerance
  • Box Latching Clearance/Tolerance
  • Base Thickness
    • This was included to make thinner bases on the boxes, saving plastic and print time.
Files Provided

Including the parametric Fusion360 file, the following files have been pre-exported as 3MFs:

  • Lower Box
  • Upper Box (with decoration)
  • Upper Box (no decoration)
Print Settings
  • Print with thick perimeters.
    • I used 1.2mm perimeters, 0.35mm layer height and 0.6mm nozzle.
