Universal Ikea Lack webcam mount

Universal webcam mount for the popular ikea lack table.
5
15
0
119
updated October 27, 2023

Description

PDF

I wanted an easy to print and webcam holder that could mount securely to the ikea lack table, so I've remixed HippieHeadShot's design from thingiverse. I've included a mount piece that screws into the table by using m2.5 countersink wood screws.

The pieces print support free, in the orientation provided. I've printed them in PLA, with 3 perimeters and 15% gyroid infill. You will need:

  • 1 x table connector
  • 1 x table mount
  • 1 x webcam mount
  • as many arms as you want (I recommand 2)

To assamble the webcam arm, start by pushing an M4 nut in the bottom of the table mount, and make it flush with the piece.

Assamble the arm by using M4 x 20 screws and M4 nuts. After you've assambled them, screw the mount into the table, and use an M4 x 10 screw to connect the arm to the table mount.

For my camera mount I've used only 2 arms, but you can use more/less. I needed the following hardware for the mount I've used:

  • 2 x M2.5 x 24 countersink wood screws
  • 1 x M4 x 10 screw
  • 3 x M4 x 20 screws
  • 4 x M4 nuts
  • 1 screw that matches the thread of the webcam (I've used a 3D printed ¼ - 20 unc screw)

Tags



Model origin

The author remixed this model.

Camera Arm - Standard Tripod Mount
by HippieHeadShot (thingiverse.com)


Differences of the remix compared to the original

I've improved on a couple of things. I've made one of the piece printable without supports, increased the webcam mount lenght to accomodate the ¼ screw head of the webcam mount, and created a separate piece that screws into the table with 2.5 x 24 mm wood screws, where we can mount with an M4 x 10 the webcam to the table (it has a pushed in M4 nut on the other side).

I also modified the holes from M5 hardware to M4 (the nuts and the bolts)
