Fanatec CSL DD Table Mount with rubber "feet"

modded table mount for Fanatec CSL DD base.
11
131
0
1456
updated October 1, 2023

Description

PDF

Basically the same as the original model, just added grooves for gluing hose flat sealings ¾" DN20 30x20x2 to add grip. As the original one, this one also requires two Bessey TK6 60/22 table clamps and 3x 16mm M6 socket head cap screws.

Printed from PETG by 0.6 nozzle, 4 perimeters (2.4mm perimeter thickness), 40% infill.

Update: Fixed angle of clamp holes.

Tags



Model origin

The author remixed this model.

Fanatec CSL DD Table Mount
by reality_boy (thingiverse.com)

Differences of the remix compared to the original

  • Added grooves for rubber feet
  • Added rim to stop on table edge
