Office Chair Headrest Adapter

Better than the "universal" mount for chairs with threaded holes 90mm apart
6
21
0
437
updated June 23, 2023

Description

PDF

I bought this headrest for my mesh office chair: https://www.amazon.com/gp/product/B09X45JGCC  It is a quality product, except for the “universal mount."  The part I designed will let you bolt it on securely to a chair with M6 tapped holes spaced 90mm apart.

Press in two M6 nuts before bolting this to the chair.  Then bolt the headrest to the mount.  Print with lots (6-8) shells for strength.  I printed it in eSUN  PLA Pro Black.

Fusion 360 and STEP models included.
