This is a 60mm Noctua fan mount adapter for the Original Xbox.
It was created to replicate the look and feel of the original Xbox fan (there are a few different fan models, but this one is based off of the Nidec fan). Improved airflow was another goal but this has not been measured.
To assemble, first put the fan cable through the left side hole (the hole above the locking fin). Then try to wiggle in the fan. It should slide in with relative ease. Attach screws that came with your Noctua fan. The screws are optional as it will stay in place without them both by friction and inside the case it will be sandwiched against the motherboard.
NOTE: Please use a 12v fan, at stock fan speed (20%) the Xbox will output 6v to the fan, however, at 100% fan speed, a full 12v will be provided.
Printer Brand: Prusa
Printer: I3 MK3S
Rafts: No
Supports: Yes
Resolution: 0.2
Infill: 15%
Filament: Prusament PLA or PETG Jet Black
Notes:
I've printed this in both PLA and PETG, both should work fine.
Lay flat and add supports from print bed.
The fan locking mechanism may be weak and break off when printed in PLA (confirmed for V0).
The author marked this model as their own original creation. Imported from Thingiverse.
