Shiley No Cuff 3.5 Ped trach (EDUCATION)

A 3D scan of a Shiley No Cuff 3.5 Ped trach for use in medical education and play design.
3
34
1
234
updated March 3, 2023

Description

PDF

This is a model based off of a 3D scan of a Shiley No Cuff 3.5 Ped trach at Ann & Robert H Lurie Children's Hospital of Chicago. It's intended use is for medical education and fostering medical play opportunities.  The inner cannel is not included but should fit 1/8" OD silicone tubing. Model is to scale but can be adjusted in the slicer to fit teddy bears, education dolls, or other resources as needed.

Print requires supports and is recommended to print at a 45° angle for strength and easier support removal. Typically printed using .12 layer heights and 20% infill.



THIS MODEL IS ONLY APPROXIMATELY REPRESENTATIVE OF ACTUAL MEDICAL HARDWARE AND SHOULD NOT BE USED FOR MEDICAL REFERENCE
