Modix V3 Clogdetector relocation mod

Moves the clog-detector to the Y axis brackets above the extruder.
8
40
0
440
updated March 31, 2023

Description

PDF

Modix V3 modification to move clog-detector to the Y axis. This makes the long PTFE reverse bowden unnecessary and with that removes a lot of friction from the system. Another good thing is that there is not as much filament left in case of a filament runout.

NOTE: do NOT forget to modify the Xmax travel in config.g to a little less. This will prevent the smashing of the detector while probing. (Will post exact values herelater)

2nd is for the secondary printhead clogdetector
