Gridfinity Snap Together Baseplate with Captured Magnets

Zack Freedman’s original Gridfinity Base Plates
https://thangs.com/designer/ZackFreedman/3d-model/Gridfinity%2520Baseplates-60925

Also inspired by https://www.printables.com/model/250550-gridfinity-magnet-light-baseplate

Optimal settings:

• To install 6x2mm magnets, add a Pause in your slicer at the beginning of the layer where the magnet holes start to get covered - see picture below
• Single external perimeter of 0.8mm with 0.4-0.6mm nozzle
• Arachne Perimeter Generator if you have it. Otherwise enable Detect Thin Walls
• Infill: 1%  (Infill isn't necessary but Prusa slicer doesn't bridge in some key areas if the infill is zero)
• Prusa Mini: disable the skirt to fit a 4x4 plate
• For edge pieces the protruding snaps can be removed using the cutting tools in your slicer

Each protruding snap has a built in support that needs to be removed after printing

Connecting a tile into a corner will be difficult, so connect tiles together in strings and then connect the strings together

Changes:

• Jan 3-2023 Added 5X and CAD files
