3D printed case for an ITX motherboard and GPU, with 2x 5.25" bays.
93h 56m
10× print file
0.15 mm
0.40 mm
861.00 g
25
81
0
2688
updated November 29, 2022

Description

PDF

Designed to be built on the Mini in PETg with as few supports required as possible, and avoiding stringing.

Printed well with my settings but filament was a bit wet.

Needs 6x80mm Fans + fixings to be used as structural members. I used M4 fixings and captive nuts (U nuts) for the rest of the assembly, and a 16mm power switch.

Works with the following computer parts:

  • Any ITX motherboard
  • ITX GPU e.g. Palit RTX 3060 Storm X or Asus RTX 3060 Phoenix
  • Low profile CPU cooler e.g. Noctua NH-L9a or L9i
  • SFX or SFX-L PSU
  • Low profile ram to suit cooler e.g. Corsair Vengeance LPX RAM

See https://uk.pcpartpicker.com/list/K84rhk for my build.

Improvement planned:

  • Add some more features to ‘lock’ parts together.
  • Add features to ‘Fan bracket’ to improve cable routing.
  • Stiffen up 'Rear panel' to prevent flexing.
  • Make version with one 5.25" bay for extra CPU cooler height
