Universal Frame Stiffener for Geeetech A20, A30; Creality CR10, CR10s; Tronxy, Sovol etc.

If you like it feel free to leave a comment or even better,buy me a "coffee": https://www.buymeacoffee.com/redangel1984

If you are looking for bracing/stiffener for your printer which uses 2040-AluminiumExtrusions for the frame, look no more you found it.
It should be compatible with a big variety of printers like:

• Creality CR10, CR10s, CR10s5 etc.
• Geeetech A20, A20M, A30, A30M etc.
• Sovol SV01
• Tronxy
  ...and many more...

Because it uses a BallJoint, the angle of the rod can be adjusted and can be used on virtually any printer.

Print instructions

IMPORTANT!!!

After you've mounted the bracing you need to fasten the ball joint rigid in place with the M3 screw, until the M3 screw tip touches the M8 rod (making a hole into the ball) and pushes this against the inner wall, creating a rigid joint

IMPORTANT!!!

Print Settings:

Supports: No

Layer height: any - (0.16-0.28)

Perimeters: 3+

Infill: >30%

Material: any - (PLA, PETG, ASA, ABS, ...)

Rafts: No
</ul>

Book of Materials(Hardware list)

No.Hardware bit

2xM8 Rod - variable length*

4xM8 Nuts

4xM8 Lock Nuts

4xM3x20 Screw

4x M3 - Square Nuts

14xM4x10 Screw

for A30, CR10, CR10s etc.:

14xM4 T-Nuts

for A20, A20M etc:

6xM4 T-Nuts

8xM4 Nuts
</table>
</p>

• • Rod length:



    Printer	Length
    Geeetech A30	680mm
    Creality CR-10, CR-10S etc.	680mm
    Geeetech A20, A20M	480mm
