Simple adapter for SKR 2 (1.4 and 3) for Anet ET4

This is a simple 2 piece motherboard mount to put an SKR 2, 1.4 or 3 (not SKR mini E3) in the Anet ET4
6
78
0
1136
updated May 24, 2022

Description

PDF

I wanted to use an SKR 2 motherboard in my Anet ET4 so I made this simple mounting system. Its a slightly unconventional position but it works well and I was able to use the original ribbon cable, with some new terminations until I get to rewiring the entire thing.

It should work with the SKR 1.4, 1.4 turbo, and the new SKR3 since they all have the same mounting pattern.
