Fox 32 Fork Seal Driver Tool

A Remix of creyc's Improved Seal Driver Tool for Fox 32 Forks. Decided to make my own version which is a bit simpler in design.

Main changes are the top part is 44mm outer diameter. Flanged seals are approx. 45mm outer diameter of the flange.

So it will work with both the flanged and flangeless seals. When using with Flangless seals the larger outer diameter prevents you from pushing the seal in too far and squashing the foam ring below. (The foam ring holds oil and helps forks to run smoothly)

Also squared up the recess for clearing the top part of the seal.

Finally made the inner part 31mm; as my Anet A8 doesn't do round parts very well. This should still keep the seal square without the tool getting stuck in the lower leg.

Note: I haven't tested this yet, so feedback appreciated. Also if anyone has dimensions for the 34 and 36mm seals I'll draw up tools for those too.

Print Settings

Printer Brand:

Anet

Printer:

A8

Rafts:

No

Supports:

No

Resolution:

0.2mm

Infill:

30%

Filament: Any PLA Any

Notes:

Use at least 3mm shell / wall and 30% infill for strength.
