Remix - Filament Motion Sensor with Optical Encoder

Remix this encoder to meet the parts I had lying around, also made some personal adjustments.

Parts

• 1 x Optical Sensor: https://www.amazon.ca/gp/product/B072R4FRDH
• 2 x MR115-2RS 5x11x4mm Bearings: https://www.amazon.ca/gp/product/B07CVBW44R
• 4 x M2x16mm Screws, Washers and Nuts
• 2 x M3x8mm Screws for mounting optical sensor
• 2 x M3x12mm Screws and T-Nuts for mounting to 2020 extrusion.
• 1 x Optional 608-size bearings for Side mount guide.

Everything was printed in PLA at 0.15-0.25 layer height, except the Axle_Wheel and the optional Side Mount Guide which was print with TPU at 0.15 layer height.

Print Settings

Printer:

Eryone Thinker S

Rafts:

Doesn't Matter

Supports:

Doesn't Matter

Resolution:

0.15-0.25

Infill:

20

Filament:

Grey, Red
