Ortur Obsidian - GCODE

Its My GCODE what i use.

Mein GCODE was is so nutze.

------------Start Code-----------------------

G21 ; set units to millimeters

G90 ; use absolute positioning

M82 ; absolute extrusion mode

M104 S{material_print_temperature_layer_0} ; set extruder temp

M140 S{material_bed_temperature_layer_0} ; set bed temp

M190 S{material_bed_temperature_layer_0} ; wait for bed temp

M109 S{material_print_temperature_layer_0} ; wait for extruder temp

G28 X0 Y0 ;move X/Y to min endstops

G28 Z0 ;move Z to min endstops

;G29 ;auto level

G0 X0 Y15 F9000 ; Go to front

G0 Z0.15 ; Drop to bed

G92 E0 ; zero the extruded length

G1 X40 E25 F500 ; Extrude 25mm of filament in a 4cm line

G92 E0 ; zero the extruded length

G1 E-1 F500 ; Retract a little

G1 X80 F4000 ; Quickly wipe away from the filament line

G1 Z0.3 ; Raise and begin printing.

--------------------EndCode-------------------------

M104 S0 ; turn off extruder

M140 S0 ; turn off heatbed

M107 ; turn off fan

G91 ; relative positioning

G1 Z25 ; raise head 25mm

G90 ; back to absolute positioning

G1 X0 Y220; home X axis and push Y forward

M84 ; disable motors
