Raspberry Pi 3 A+ Case

Designed a minimal case for the Raspberry Pi 3 A+ to match my Pi0W Case. It has openings for Power, HDMI, Audio, USB, microSD. I have a plain top as well as a top with an opening for the GPIO pins. ~~I will add a top that has openings for the camera and display ports as well.~~ The bottom has an opening to let you pop your Pi out using your finger.

The pins on the underside of the USB port may stick out a little more than my model. You may need to gently bend them inward if you have any issues getting it full seated in the bottom.

EDIT: Added new tops with holes. In addition to a plain top with no holes, the following options are now available:

• Camera opening
• Display opening
• GPIO opening
• Camera and Display openings
• Camera and GPIO openings
• Display and GPIO openings
• Camera, Display, and GPIO openings

Print Settings

Printer Brand:

PowerSpec

Printer:

PowerSpec 3D Pro

Rafts:

No

Supports:

Yes

Resolution:

.2mm

Infill:

10-15 should be plenty

Notes:

Depending on your bridinging you may need supports for the microSD slot on the bottom shell.
