Arrma Infraction Rock deflector/ Wheel wells

Please share the link back to this thing when you share your builds! Its part of the attribution license I shared this…
16
114
1
879
updated March 11, 2023

Description

PDF

Please share the link back to this thing when you share your builds! Its part of the attribution license I shared this under, Thank You!

Side skirts fit on a cr-10 size bed, wheel arches fit on smaller printers. Split skirts coming soon

You will need 10-20 6-12mm m3 flat head screws to mount the arches to the side skirts, I ran with only 2 screws per arch during testing just fine with only 6mm long screws, holes support up to 12mm though.

If you like the design please consider tipping so I can buy more tires or different bodies.

5/13:

Added templates for drilling out existing skirts, align the front and rear 2 holes.

Added a split side skirt

3/10/23

Added Step and Fusion 360 Files of skirts and wheel arches



Print Settings

Supports:

Yes




Notes:



Rear arch needs supports, block supports from generating in screw holes. For the time being mirror for left side

Category: R/C Vehicles
