Here i will share any 3d models for KiCad parts that i made.
2
21
0
182
updated January 21, 2024

Description

PDF

I have started using KiCad lately and i absolutely love it's 3D view feature but some parts that i was using had missing 3D models so i made them myself. Here i will share these models.

All models are fully coloured.

Current list of models:
-SOD80 Zener diode
-ESOP-8 (TP4056 uses it) package
-3x6x2,5mm SMD Button
-DG300-5.0 RM=5mm Terminal block
